AIM Installation and Removal
Figure 57 Metal Standoffs
Step 3 Install the two machine-thread metal standoffs in place of the two screws labeled A in Figure 56. Use a
1/4-inch nut driver to tighten the standoffs. See Figure 58.
Caution Make sure that the standoffs are straight when installed. Tighten them gently but firmly. The shoulder
must be seated tight against the motherboard.
