Cisco 3845 - Security Bundle Router Quick Start Guide

13
Figure 7 Bracket Installation for Center Mounting with Front Panel Forward
Figure 8 Bracket Installation for Center Mounting with Rear Panel Forward
Installing the Router in a Rack
Caution Be sure to leave space above and below each router in a rack, to allow for cooling air circulation.
Warning
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest component
at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in the rack.
Statement 1006
Left bracket
for 23-inch rack
117985
Left bracket
for 19-inch rack
Use six screws on each side.
Right bracket
for 19-inch rack
Right bracket
for 23-inch rack
Left bracket
for 23-inch rack
E
N
N
M
-
E
SW
-
16
15x
7x
14x
6x
13x
5x
FastEthernet Ports
12x
4x
11x 3x
10x
2x
9x
1x
8x
0x
E
x
t
P
w
r
-48V
0x
8x
7x
15x
GE
10/100/
1000
Base-Tx
117986
Right bracket
for 19-inch rack
Right bracket
for 23-inch rack
Left bracket
for 19-inch rack
Use six screws on each side.
