BehaviorColorLED LabelNo.
Blink frequency indicates
port speed:
1 blink - 10 Mbps link
speed
2 blink - 100 Mbps link
speed
3 blink - 1000 Mbps link
speed
Blinking greenWAN port speed LED8
Ethernet cable present and
link established
GreenWAN port link LED9
Indicates SFP module
detected
GreenWAN port SFP enable
LED
10
Indicates SFP is not
detected or at fault
Amber
Blink frequency indicates
port speed:
3 blink - 1000 Mbps link
speed
Blinking green
WAN port SFP speed
LED
11
HDD presentGreenHDD status LED12
HDD is in rebuilt state.Blinking green
HDD is in a fault stateAmber
HDD is in a PFA alert
state
Blinking amber
The hard drive is reading
or writing data.
Blinking green
HDD activity LED13
