CHAPTER 2
Technical Details
• Physical and Operating Environment Specifications, on page 11
• Cable Specifications, on page 12
• Network and Computer Port Pinouts, on page 13
• Phone Power Requirements, on page 14
• Network Protocols, on page 16
• VLAN Interaction, on page 20
• External Devices, on page 20
Physical and Operating Environment Specifications
The following table shows the physical and operating environment specifications for the Cisco IP Phone 6800
Series Multiplatform Phones.
Table 1: Physical and Operating Specifications
Value or RangeSpecification
32° to 104°F (0° to 40°C)Operating temperature
10% to 90% (noncondensing)Operating relative humidity
14° to 140°F (–10° to 60°C)Storage temperature
10% to 95% (noncondensing)Storage relative hunidity
8.14 in. (207 mm), excluding the footstandHeight
6821: 6.73 in. (171 mm)
6841, 6851, and 6861: 8.11 in. (206 mm)
Width
6821: 1.48 in. (37.5 mm), excluding the footstand
6841, 6851, and 6861: 1.30 in. (33 mm), excluding
the footstand
Depth
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
11
