Figure 7: RJ45 Connector in the Phone Jack
Network Port on the Phone1
RJ45 Connector2
Step 4 Plug the RJ45 connector into the wall mount phone jack as shown in the following figure.
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
111
Phone Accessories
Install the Cisco IP Phone 6821 Multiplatform Phones on a Wall
