Ext Status
DescriptionParameter
Shows “Registered” if the phone is registered, or “Not
Registered” if the phone is not registered to the ITSP.
Registration State
Last date and time the line was registered.Last Registration At
Number of seconds before the next registration
renewal.
Next Registration In Seconds
Indicates whether message waiting is enabled or
disabled.
Message Waiting
Port number of the SIP port mapped by NAT.Mapped SIP Port
Indicates whether Hoteling is enabled or disabled.Hoteling State
Indicates whether extended function is enabled.Extended Function Status
Line Call Status
DescriptionParameter
Status of the call.Call State
Type of tone that the call uses.Tone
Codec used for encoding.Encoder
Codec used for decoding.Decoder
Direction of the call.Type
Indicates whether the far end placed the call on hold.Remote Hold
Indicates whether the call was triggered by a call back
request.
Callback
The port mapped for Real Time Protocol traffic for
the call.
Mapped RTP Port
Name of the internal phone.Peer Name
Phone number of the internal phone.Peer Phone
Duration of the call.Duration
Number of packets sent.Packets Sent
Number of packets received.Packets Recv
Number of bytes sent.Bytes Sent
Number of bytes received.Bytes Recv
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
213
Phone Troubleshooting
Ext Status
