Cisco 6821 Administration Guide

DescriptionParameter
Allows you to select Speed and duplex of the
Computer (access) port.
• Auto
• 10MB half
• 10MB full
• 100 MB half
• 100MB full
• 100 half
• 1000 full
PC Port Config
Specifies if PC port is enabled. Options are Yes or
No.
PC PORT Enable
Adds the ability to port mirror on the PC port. When
enabled, you can see the packets on the phone. Select
Yes to enable PC port mirroring and select No to
disable it.
Enable PC Port Mirror
Specify the syslog server name and port. This feature
specifies the server for logging IP phone system
information and critical events. If both Debug Server
and Syslog Server are specified, Syslog messages are
also logged to the Debug Server.
Syslog Server
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
226
Phone Troubleshooting
Optional Network Configuration

Cisco 6821 Specifications

General

Resolution	320 x 240 pixels
Speakerphone	Yes
Headset Port	Yes
Protocols	SIP
USB Port	No
Wireless	No
Bluetooth	No
Video Support	No
Conference Capabilities	Yes
Wall Mountable	Yes
Display	3.5-inch grayscale
Ethernet	10/100 Ethernet
Line Keys	2
PoE	IEEE 802.3af Power over Ethernet (PoE)
Codecs	G.711, G.722, G.729, iLBC
Weight	2.0 lb (0.91 kg)
