DescriptionDefaultField Type
or Choices
Field
Enable or disable LLDP-MED.
LLDP-MED enables the phone to advertise itself to devices that
use the discovery protocol.
OnOn
Off
LLDP-MED
Set a value that causes a delay for the switch to get to the
forwarding state before the phone sends out the first LLDP-MED
packet. For configuration of some switches, you might need to
increase this value to a higher value for LLDP-MED to work.
Configuring a delay can be important for networks that use the
Spanning Tree Protocol.
Default delay is 3 seconds.
3 secondsStartup delay
Enable or disable VLAN.
Permits you to enter a VLAN ID when you use VLAN without
CDP or LLDP. When you use a VLAN with CDP or LLDP, that
associated VLAN takes precedent over the VLAN ID you
manually entered.
OffOn
Off
VLAN
Enter a VLAN ID for the IP phone when you use a VLAN without
CDP (VLAN enabled and CDP disabled). Note that only voice
packets are tagged with the VLAN ID. Do not use the 1 value for
the VLAN ID. If VLAN ID is 1, you cannot tag voice packets
with the VLAN ID.
1VLAN ID
Enter a value of the VLAN ID that is used to tag communications
from the PC port on the phone.
The phone tags all the untagged frames coming from the PC (it
does not tag any frames with an existing tag).
Valid values: 0 through 4095
Default: 0
1PC port VLAN ID
Adds the ability to port mirror on the PC port. When enabled, you
can see the packets on the phone. Select On to enable PC port
mirroring and select Off to disable it.
OffOn
Off
PC port mirror
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
41
Phone Installation
Network Configuration Fields
