6 OL-11414-01
The following graphic and table show how to connect the Cisco Unified IP Phone 7911G:
1
Network port (10/100 SW)
4
DC adapter port (DC48V)
2
Access port (10/100 PC)
5
AC-to-DC power supply
3
Handset port
6
AC power cord
3
2
4
6
5
1
91638
