2-2
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 810 ISR
restricted access location and users and service people who are authorized within the restricted
access location are made aware of the hazard. A restricted access area can be accessed only
through the use of a special tool, lock and key or other means of security. Statement 1072
Items Shipped with your Router
Unpack the box and verify that all items listed on the invoice were shipped with the Cisco 812 ISR.
The following items are shipped with your router:
• AC power adapter
• Accessory kit 53-3453-01 which contains the following:
– Pointer document 78-19961-01
– RCSI document 78-17665-05
– Console cable 72-3383-01
• Mounting bracket kit C810-BR-CM
– Includes screws needed for the installation
• Two 3G Dipole antennas
Items Shipped with your PoE+ Splitter
Unpack the box and verify that all items listed on the invoice were shipped with the Cisco PoE+ splitter
(C810-POE-SPL).
The following items are shipped with your PoE+ splitter:
• GE Cat5 cable
• Power cable
• Power cord lock
• Screws needed for the installation
• Shelf bracket
Note The above items are acceptable for use in Plenums and Air-handling spaces.
Installing the Cisco PoE+ Splitter
The PoE+ splitter (C810-POE-SPL) is an optional accessory that is intended to be mounted to the ceiling
tile rails (24 inches span) using the only supported box hanger available from a Cooper B-line BA50
distributor. The screws, cables, and power cord lock needed for the installation are included in the PoE+
splitter accessory kit. A 5 VDC power cable with 1.3 meters in length connects the 5 VDC output of the
PoE+ splitter to the router power input.
To install the Cisco PoE+ splitter, perform these steps:
Step 1 Secure the PoE+ splitter mounting plate into the rail from the BA50 with two 10-24 screws (see
Figure 2-1).
