2-6
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 810 ISR
Figure 2-5 T-Rail
Installing the SIM Card
This section describes how to install and replace the SIM card. Ensure that the router is not mounted to
a wall, rack, or DIN rail.
Caution Do not touch any part of the exposed PCB circuit area when the SIM cover is removed.
Warning Hot surface. Statement 1079
To install the SIM card, perform these steps:
Step 1 Power off the router and disconnect the power cable from the power source.
Step 2 Place the router on a sturdy solid surface and orient the SIM access panel up to gain access. Ensure that
any installed antennas are oriented appropriately to avoid damage.
Step 3 Remove the SIM access panel being held in place by four 6-32 screws. (See Figure 2-6).
285669
To POE Power
Source
