A-3
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16193-03
Appendix A Technical Specifications
Wireless Access Point
Wireless Access Point
Table A-2 lists the specifications for the wireless access point (AP).
FE and GE Port Pinouts
Table A-3 lists the pinouts for the Ethernet ports.
Ta b l e A-2 Wireless Access Point Specifications
Description Design Specification
Radio technology IEEE 802.11n draft 2.0 standard compliant. 2x3
MIMO
1
radio. Backward compatible with
802.11b/g and 802.11a (Cisco 890 series routers).
1. Multiple Input/Multiple Output.
Operating frequency
Cisco 860 series and 880 series ISRs
2.4-GHz radio band
Cisco 890 series ISRs
2.4 and 5-GH radio bands
Channels Country-specific 20 and 40 MHz
PHY Data rate 802.11b up to 11 Mb/s
802.11g up to 54 Mb/s
802.11n up to 300 Mb/s
Ta b l e A-3 Ethernet LAN Port Pinouts
Pin Function
1 RX+
2 RX–
3 TX+
4 Unused
5 Unused
6 TX–
7 Unused
8 Unused
