Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16193-03
Chapter 2 Installing the Router
Equipment, Tools, and Connections
Items Shipped with your Router
Unpack the box and verify that all items listed on the invoice were shipped with the router.
Table 2-1 lists the items and their quantities that are shipped with each router model.
Additional Items
The following items are not shipped with the router but are required for installation:
• ESD-preventive cord and wrist strap.
• Screws for mounting the router on a wall:
– Two number-10 wood screws (round- or pan-head) with number-10 washers, or two number-10
washer-head screws, for mounting on a wall stud. The screws must be long enough to penetrate
at least 3/4 in. (20 mm) into the supporting wood or metal wall stud.
– Two number-10 wall anchors with washers, for mounting the router on a hollow-wall.
• Wire crimper for chassis grounding.
• Wire for connecting the chassis to an earth ground:
– AWG 14 (2 mm
2
) or larger wire for NEC-compliant chassis grounding.
– AWG 18 (1 mm
2
) or larger wire for EN/IEC 60950–compliant chassis grounding.
• A ring terminal with an inner diameter of 1/4 in. (5 to 7 mm), for NEC-compliant chassis grounding.
• Ethernet cables for connecting to the Fast Ethernet (FE) WAN and LAN ports.
Connections
Obtain a broadband or Ethernet connection from your service provider.
Ta b l e 2-1 Items and Their Quantities That Are Shipped with the Cisco 860 Series, Cisco 880
Series, and Cisco 890 Series ISRs
Item
Cisco 860
Series Routers
Cisco 880
Series Routers
Cisco 890
Series Routers
Straight-through RJ-45 Ethernet cable
1
1. Cisco 861 and Cisco 881 ISRs only.
1 1 1
RJ-11 DSL
2
cable
3
2. DSL = digital subscriber line.
3. Cisco 888 ISRs only.
1 1 1
RJ-45–to–DB-9 console cable 1 1 1
External 12 VDC power supply adapter 1 1 1
AC power supply cable 1 1 1
Cisco Configuration Professional (Cisco CP)
CD
4
4. Cisco CP is optional by order and available only on some SKUs.
1 1 1
