Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16193-03
Appendix A Technical Specifications
Console and Auxiliary Port Connector Pinouts
Console and Auxiliary Port Connector Pinouts
Table A-4 lists the pinouts for the console and auxiliary port connectors.
FXS and FXO Port Connector Pinouts
Table A-6 lists the FXS and FXO connector pinouts.
VDSL2 Port Connector Pinouts
Table A-6 lists the VDSL2 connector pinouts.
Ta b l e A-4 Console and Auxiliary Port Connector Pinouts
RJ-45 Pin Function
1 RTS
2 DTR
3 TXD
4 GND
5 GND
6 RXD
7 DSR
8 CTS
Ta b l e A-5 FXS and FXO Connector Pinouts (RJ-11-to-RJ-45)
Pin Signal
1 NC
2 NC
3 TIP
4 RING
5 NC
6 NC
Ta b l e A-6 VDSL2 Connector Pinouts (RJ-11-to-RJ-45)
RJ-11 Pin Function
1 Unused
2 Unused
3 TIP
4 RING

Cisco 881W - Integrated Services Router Wireless Specifications

General

Brand	Cisco
Model	881W - Integrated Services Router Wireless
Category	Wireless Router
Language	English
