1-19
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16193-03
Chapter 1 Product Overview
Hardware Features
3G Cellular Data WAN Connectivity
The 3G (Evolution Data Only [EVDO], Universal Mobile Telecommunications Systems [UMTS])
cellular interface is intended for use as a backup data link, but it can also be used as a primary WAN data
link. The 3G technology is third-generation wide-area cellular technology that is used in voice telephony
and broadband wireless data in a mobile environment.
The Cisco 88xG models come with a 34-mm express card slot ready for use with a commercial 3G card
radio. The 3G express card slot is located on the front panel. For a list of supported 3G cards, see the
Cisco 880 Series Integrated Services Routers data sheet.
Wireless LAN Connectivity
The embedded Wi-Fi CERTIFIED™, 802.11a/b/g/n-compliant wireless AP is preinstalled in the router
as an optional feature. The Cisco 860 series routers support autonomous features and network
configurations. The Cisco
880 series and 890 series routers support both autonomous and unified
features and network configurations.
The wireless AP does not have an external console port. Use the router’s console port as described in
Chapter 3, “Connecting a Terminal or PC to the Console Port.” To configure the wireless device, use the
Cisco IOS command-line interface (CLI).
Table 1-2 describes the radios and antennas for the Cisco 860 series, 880 series, and 890 series routers.
The 5-GHz radio operates in the Unlicensed National Information Infrastructure (UNII) 1, 2, 3, 5-GHz
frequency bands.
Ta b l e 1-2 Wireless Device Radios and Antennas
Radio Module Platform Radio Band
Maximum Data
Throughput
1
1. Actual data rate is highly dependent on your wireless environment.
Mode Antenna
Single-band
802.11b/g/n draft 2.0
radio module
Cisco 860 and
880 series
routers
2.4 GHz Up to 100 Mb/s Cisco 860 series:
autonomous only
Cisco 880 series:
autonomous and
unified
Three captive 2-dBi
omnidirectional dipole
antennas
Dual-band
simultaneous
802.11a/n and
802.11b/g/n
radio module
Cisco 890 2.4 GHz
and 5 GHz
100 Mb/s per radio,
up to 200 Mb/s
total
Autonomous and
unified
Three dual-band,
removable,
2.4-GHz/5-GHz
omnidirectional dipole
RP-TNC antenna
2
2. The antennas require some minor installation. They must be screwed onto the RP-TNC antenna connectors on the I/O side of the chassis. See the
following document on Cisco.com for feature information:
http://cisco.com/en/US/products/ps5853/prod_installation_guide09186a00804399cd.html
