Cisco A9K-SIP-700 Service Configuration Guide

Configuring Modular QoS Congestion Management on Cisco ASR 9000 Series Routers
How to Configure QoS Congestion Management on Cisco ASR 9000 Series Routers
QC-64
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Step 5
conform-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
conform-action set mpls experimental topmost 3
Configures the action to take on packets that conform to the
rate limit. The action argument is specified by one of the
following keywords:
• drop—Drops the packet.
• set—Has the following keywords and arguments:
– cos value—Sets the class of service value. Range is
0 to 7.
– discard-class value—Sets the discard class value.
Range is 0 to 7.
– dscp value—Sets the differentiated services code
point (DSCP) value and sends the packet.
– mpls experimental {topmost | imposition}
value—Sets the experimental (EXP) value of the
Multiprotocol Label Switching (MPLS) packet
topmost label or imposed label. Range is 0 to 7.
– precedence precedence—Sets the IP precedence
and sends the packet.
– qos-group—Sets the QoS group value. Range is 0
to 63.
• transmit—Transmits the packets.
Step 6
exceed-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
exceed-action set mpls experimental topmost 4
Configures the action to take on packets that exceed the rate
limit. The action argument is specified by one of the
keywords specified in
Step 5.
Step 7
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
exit
Returns the router to policy map class configuration mode.
Step 8
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# exit
Returns the router to policy map configuration mode.
Step 9
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap)# exit
Returns the router to global configuration mode.
Step 10
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
gigabitethernet 0/5/0/0
Enters configuration mode and configures an interface.
Command or Action Purpose
