Key Ports and Components
Familiarize yourself with the access point before continuing with the installation. Figure 2 shows the
access point key components.
Figure 2 Access Point Ports and Connections
1
Standard ceiling adjustable T-rail clip
3
1140 series access point
2
Mounting bracket
4
6-32 x 1/4 in. (0.63 cm) flat head screws
1
Kensington lock slot
4
Console port
2
Power connection
5
Security padlock and hasp
3
Ethernet port
6
Low-profile mounting bracket pins (feet for
desk or table-top mount)
272377
2 3 4
1 5
6 6
