Cisco Aironet 1815i - Page 13

13
Figure 6 Access Point Ports and Mode Button
Figure 7 AIR-AP-BRACKET-8
1
RJ-45 console port
2
PoE-In port (Ethernet Uplink port)
3
Mode button.
For information on how to use the Mode button, see “Using the Mode Button” section on
page 23.
354897
1 2 3
354898
