Cisco AS5350XM - Appendix; Cabling Specifications

A-1
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Card Installation Guide
78-17406-01
APPENDIX
A
Cabling Specifications
This appendix provides cabling and pinout information for feature cards on the Cisco AS5350XM and
Cisco AS5400XM universal gateways. It contains the following sections:
• 2-Port and 4-Port T1 or E1 Feature Card Cable and Port Pinouts, page A-1
• 8-Port T1 or E1 Feature Card Cable and Port Pinouts, page A-6
• CT3 Feature Card Cable and Port Pinouts, page A-12
• Bantam Jack Port Pinouts, page A-13
Note This appendix specifies pinouts only for the pins used. Pins not listed in the tables in this appendix are
not connected.
2-Port and 4-Port T1 or E1 Feature Card Cable and Port Pinouts
Table A-1 lists the T1 or E1 feature card port pinouts.
Table A-1 T1 or E1 Feature Card Port Pinouts
RJ-45 Pin Description
1 RX tip
2RX ring
3 RX shield
4TX tip
5TX ring
6 TX shield
7—
8—
