Cisco AS5350XM Installation Guide

A-13
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Card Installation Guide
78-17406-01
Appendix A Cabling Specifications
Bantam Jack Port Pinouts
Figure A-12 shows a diagram of the CT3 feature card cable assembly.
Figure A-12 CT3 Feature Card Cable Assembly
Bantam Jack Port Pinouts
Table A-13 lists the bantam jack port pinouts.
12951
Table A-13 Bantam Jack Port Pinouts
Pin Description
1Tip
2Ring
