Cisco ASA 5506-X Installation Guide

• Desk mountable; see Desktop-Mount the Chassis, on page 27 for more
information.
Do not stack the ASA chassis on top of another ASA chassis. If
you stack the units, they will overheat, which causes the units to
power cycle.
Caution
• Rack mountable in a rack tray. You can place two chassis side by side. See
Rack-Mount the Chassis, on page 29 for more information.
One ASA 5506H-X fits in the rack tray. See Rack-Mount the
Chassis, on page 29 for more information.
Note
• Wall mountable (ASA 5506-X and ASA 5506W-X only); see Wall-Mount
the Chassis, on page 28 for more information.
• DIN rail mountable (ASA 5506H-X only); the DIN rail is available for order
from Cisco Systems. See Install the ASA 5506H-X in a DIN Rail, on page
30.
Mounting
7.87 x 9.23 x 1.94 in (19.99 x 23.44 x 4.93 cm) including the feet (ASA 5506-X
and ASA 5506W-X).
9.1 x 9.1 x 2.8 in (23.11 x 23.11 x 7.11 cm) including the feet (ASA 5506H-X).
Dimensions
4 lb (ASA 5506-X and ASA 5506W-X)
6.7 lb (ASA 5506H-X)
Weight
Total: 4 GB
Allotted to FW/VPN: 1.8 GB
Allotted to Module: 2.2 GB
The total memory is divided between the OS/Lina/SFR. These
percentages may vary depending on your ASA software version.
Note
DRAM
8 GBInternal flash
60 W (ASA 5506-X and ASA 5506W-X)
22 W (5506H-X)
Power
Operating: 32 to 104°F (0 to 40°C) (ASA 5506-X and ASA 5506W-X)
1
-4 to 140°F (-20 to 60°C) (ASA 5506H-X)
2
Nonoperating: -13 to 158°F (-25 to 70°C) (ASA 5506-X and ASA 5506W-X)
-40 to +185°F (-40 to +85° C) (ASA 5506H-X)
Temperature
Operating: 90% (ASA 5506-X and ASA 5506W-X)
Operating: 95% (ASA 5506H-X)
Nonoperating: 10 to 90%
Relative humidity
Cisco ASA 5506-X, ASA 5506W-X, and ASA 5506H-X Hardware Installation Guide
Online Only12
Overview
Hardware Specifications

Cisco ASA 5506-X Specifications

General

Model	ASA 5506-X
Firewall Throughput	750 Mbps
Maximum Firewall Connections	50, 000
Maximum VPN Peers	50
Integrated Ports	8 x 1 GE
Stateful Inspection Throughput	750 Mbps
Weight	4.4 lb (2 kg)
Firewall Throughput (Multiprotocol)	750 Mbps
Firewall Throughput (Application Visibility and Control AVC)	250 Mbps
Concurrent Sessions	50, 000
New Connections per Second	10, 000
IPsec VPN Throughput	100 Mbps
Interfaces	8 x 1 GE
Memory	4 GB
Flash Memory	8 GB
Form Factor	Desktop
VPN Throughput	100 Mbps
Maximum Concurrent Sessions	50, 000
New Sessions per Second	10, 000
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-13 to 158°F (-25 to 70°C)
Power Supply	External
Humidity	10% to 90% non-condensing
