CHAPTER 5
Installation, Maintenance, and Upgrade
Connect the DC Adapter for the 5506H-X, on page 39
Install the Adjustable Power Supply Retainer, on page 40
Connect the DC Adapter for the 5506H-X
You can order an optional DC power supply that supplies 24V DC (part number PWR2-20W-24VDC) or
20W 20-60V DC (part number PWR2-22W-20-60VDC).
Statement 1005
This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than 36 VDC, 5A.
Warning
This product requires short-circuit (overcurrent) protection to be provided as part of the building installation.
Install only in accordance with national and local wiring regulations.
Warning
The device is designed to work with TN power systems.
Warning
Step 1 Connect the black and white lead wires to a 12 VDC source.
The black lead is negative or ground and the white lead is positive. The output cable is 1.3 meters and the input cable is
1 meter in length.
