Cisco ASR 9000 Series Configuration Manual

Configuring Serial Interfaces on the Cisco ASR 9000 Series Router
How to Configure Serial Interfaces
519
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
11. exit
12. exit
13. show interfaces serial [interface-path-id]
Command or Action Purpose
Step 1
configure
Example:
RP/0/0RP0RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
interface serial interface-path-id
Example:
RP/0/0RP0RSP0/CPU0:router(config)# interface
serial 0/1/0/0
Specifies the serial interface name and notation
rack/slot/module/port, and enters interface configuration
mode.
Step 3
encapsulation [hdlc | ppp | frame-relay [IETF]
Example:
RP/0/0RP0RSP0/CPU0:router(config-if)#
encapsulation hdlc
(Optional) Configures the interface encapsulation
parameters and details such as HDLC, PPP or Frame Relay.
Note The default encapsulation is hdlc.
Step 4
serial
Example:
RP/0/0RP0RSP0/CPU0:router(config-if)# serial
(Optional) Enters serial submode to configure the serial
parameters.
Step 5
crc length
Example:
RP/0/0RP0RSP0/CPU0:ios(config-if-serial)# crc
32
(Optional) Specifies the length of the cyclic redundancy
check (CRC) for the interface. Enter the 16 keyword to
specify 16-bit CRC mode, or enter the 32 keyword to
specify 32-bit CRC mode.
Note The default is CRC length is 16.
Step 6
invert
Example:
RP/0/0RP0RSP0/CPU0:ios(config-if-serial)#
inverts
(Optional) Inverts the data stream.
Step 7
scramble
Example:
RP/0/0RP0RSP0/CPU0:ios(config-if-serial)#
scramble
(Optional) Enables payload scrambling on the interface.
Note Payload scrambling is disabled on the interface.
Step 8
transmit-delay hdlc-flags
Example:
RP/0/0RP0RSP0/CPU0:ios(config-if-serial)#
transmit-delay 10
(Optional) Specifies a transmit delay on the interface.
Values can be from 0 to 128.
Note Transmit delay is disabled by default (the transmit
delay is set to 0).
