A-6
Cisco ASR 9001 and Cisco ASR 9001-S Routers Hardware Installation Guide
OL-26701-02
Appendix A Technical Specifications
Table A-12 lists the supported CWDM SFP transceivers modules and describes their operating parameters.
Table A-13 lists the supported
DWDM SFP transceivers modules and describes their operating parameters.
SFP-10G-LR Cisco SFP+ for 10-Gigabit Ethernet
Long Reach
1310 nm SMF 6.21 miles (10 km)
SFP-10G-SR Cisco SFP+ for 10-Gigabit Ethernet
Short Reach
850 nm 62.5 micron (FDDI
grade)
62.5 micron (OM1
grade)
50 micron (OM2 grade)
50 micron (OM3 grade)
82.02feet (25m)
65.62feet (20m)
262.47 feet (80 m)
984.25 feet (300 m)
Table A-11 Supported SFP+ Transceivers (continued)
Part Number Description Wavelength Fiber Type
Typical Maximum
Distance
Table A-12 Supported CWDM SFP Transceivers
Part Number Description Wavelength Fiber Type Color Identifier
CWDM-SFP-1470 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1470 nm SMF Gray
CWDM-SFP-1490 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1490 nm SMF Violet
CWDM-SFP-1510 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1510 nm SMF Blue
CWDM-SFP-1530 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1530 nm SMF Green
CWDM-SFP-1550 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1550 nm SMF Yellow
CWDM-SFP-1570 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1570 nm SMF Orange
CWDM-SFP-1590 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1590 nm SMF Red
CWDM-SFP-1610 Cisco CWDM SFP for Gigabit Ethernet and 1G/2G FC 1610 nm SMF Brown
Table A-13 Supported DWDM SFP Transceivers
Part Number Description Wavelength ITU Grid
DWDM-SFP-5979 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1559.79 nm 22
DWDM-SFP-5898 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1558.98 nm 23
DWDM-SFP-5817 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1558.17 nm 24
DWDM-SFP-5736 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1557.36 nm 25
DWDM-SFP-5655 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1556.55 nm 26
DWDM-SFP-5575 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1555.75 nm 27
DWDM-SFP-5494 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1554.94 nm 28
DWDM-SFP-5413 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1554.13 nm 29
DWDM-SFP-5332 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1553.32 nm 30
DWDM-SFP-5252 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1552.52 nm 31
DWDM-SFP-5172 Cisco 1000BASE-DWDM SFP (100 GHz ITU grid) 1551.72 nm 32
