Figure 203: Replacing the Cisco ASR 9906 Router Chassis Air Filter
• For the Cisco ASR 9006 Router and Cisco ASR 9904 Router, loosen the thumb screw that secures the
filter to the chassis, and then slide the air filter out of the chassis.
Figure 204: Replacing the Cisco ASR 9006 Router Chassis Air Filter
Thumb screw2Air filter1
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
226
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Cisco ASR 9001 Specifications

General

Router Series	ASR 9000 Series
Rack Units	2 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Power Supply	AC or DC
Memory	8 GB
Forwarding Capacity	Up to 80 Gbps
Switching Capacity	160 Gbps
Operating Temperature	0 to 40°C
Weight	24 lb
Redundancy	Power supply
