Cisco ASR 903

Step 5
Using a crimping tool (as specified by the ground lug manufacturer), crimp the ground lug to the ground wire and connect
the other end of the ground wire to a suitable grounding point at your site. See figure below.
Figure 11: Attaching the Ground Lug and Wire Assembly
Dual ground screws2Dual-hole ground adapter
and dual-hole lug
1
Step 6
Position the plenum assembly to the rack and secure the cable brackets to the rack using a torque of 11.5 in.-lb (1.3 N-m).
See figure below.
Cisco ASR 903 and ASR 903U Aggregation Services Router Hardware Installation Guide
12
Installing the Cisco ASR 903 Router
Installing the Router Chassis in the Rack
