If a User Account Control warning appears, click “Allow - I trust this program...” to proceed.
Note
Step 5
When the InstallShield Wizard Completed window appears click Finish.
Connecting to the Auxiliary Port
When a modem is connected to the auxiliary port, a remote user can dial in to the router and configure it. Use
a light blue console cable and the DB-9-to-DB-25 connector adapter.
The console cable and DB-9-to-DB-25 connector are not included with the Cisco ASR 903 Router; they
are ordered separately.
Note
To connect a modem to the router, follow these steps:
Step 1
Connect the RJ45 end of the adapter cable to the black AUX port on the router, as shown in the figure below .
Figure 32: Connecting a Modem to the Cisco ASR 903 Router
Cisco ASR 903 and ASR 903U Aggregation Services Router Hardware Installation Guide
51
Installing the Cisco ASR 903 Router
Connecting to the Auxiliary Port
