Cisco ASR 903 Installing Guide

The mounting brackets and cable mounting brackets are assembled together. We recommend that the
brackets are installed before the chassis is installed in the Air Plenum.
Note
To install the optional cable management brackets, perform these steps:
Step 1
Position the cable management brackets against the front of the chassis and align the four screw holes, as shown in the
figure below.
Figure 15: Cable Management Bracket Installation
Figure 16: Cable Management Bracket (A903-CAB-BRACKET)
Step 2
Secure the cable management brackets with four M4 screws. The recommended maximum torque is 10 in.-lb (1.12 N-m).
Cisco ASR 903 and ASR 903U Aggregation Services Router Hardware Installation Guide
16
Installing the Cisco ASR 903 Router
Attaching the Cable Management Brackets
