Cisco C1101-4P Hardware Installation Guide

RXTXTechnologyAntenna
Port
B1, B2, B3, B4, B5, B6, B8, B9, B19
-3G
WDCMA
ANT 1
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17,
B18, B19, B20, B25, B26, B28, B29, B30, B32,
B34, B38, B39, B40, B41, B42, B43, B46, B48,
B66, B71
B5, B20, B42, B43, B48, B71LTE
n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40,
n41, n48, n66, n71, n77, n78, n79
n5, n48, n77, n78, n795G NR FR1
-
-3G
WDCMA
ANT 2
B1, B2, B3, B4, B7, B25, B30, B32, B34, B38, B39,
B40, B41, B42, B43, B46, B48, B66
B1, B2, B3, B4, B7, B41, B66LTE
n1, n2, n3, n7, n25, n38, n40, n41, n48, n66, n77,
n78, n79
n1, n2, n3, n7, n25, n41, n66,
n77, n78, n79
5G NR FR1
-
-3G
WDCMA
ANT 3
B1, B2, B3, B4, B7, B25, B30, B32, B34, B38, B39,
B40, B41, B42, B43, B46, B48, B66
-LTE
n1, n2, n3, n7, n25, n38, n40, n41, n48, n66, n77,
n78, n79
-5G NR FR1
LED Behaviors
The following table lists the LED indicators and their behavior. The LEDs provide a visual indication of the
status and the currently selected services.
LED Indicators:
FunctionColorLED
Enable LEDGreen, YellowEN
• Pluggable enable LED
• Off: System power is off
• Yellow: Module power is not functioning correctly
• Green: Module power is on
SIM0 LED/ActivityGreen, YellowSIM0
• SIM0 LED status and WWAN activity
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
71
Install and Upgrade Internal Modules and Field Replaceable Units
LED Behaviors

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
