Figure 56: LTE Pluggable - C1118-8PLTEAP

DescriptionItem

Mini-PCIE1

Common heat spreader + thermal interface2

I/O3

Enclosure base to support 4-antenna4

4-1 SMA-MHF4 cable assembly5

SMA Diversity Antenna for usability and Micro-USB port access6

Figure 57: LTE Pluggable - C1118-8PLTEAP Back Panel

Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router

Install and Upgrade Internal Modules and Field Replaceable Units

Install an LTE Pluggable Module on a C1101-4P
