Cisco C1121-4PLTEP User Manual

CHAPTER 3
Install and Connect the Router
This chapter describes how to install and connect Cisco 1000 Series Integrated Services Router to LAN and
WAN networks.
Read the installation instructions before using, installing or connecting the system to the power source.
Statement 1004
Warning
Installing the Cisco 1000 Series Integrated Services Router involve these tasks:
• Unpack the Router, on page 31
• Set up Router on Desktop, Rack, or Wall, on page 31
• Connect Power Cable, on page 49
• Connect the Router to a Console, on page 51
• Connect WAN and LAN Interfaces, on page 55
• Configure the Router at Startup, on page 56
Unpack the Router
Unpack the router only when you are ready to install it. If the installation site is not ready, to prevent accidental
damage, keep the chassis in its shipping container until you are ready to install.
The router, accessory kit, publications, and any optional equipment you order may be shipped in more than
one container. When you unpack the containers, check the packing list to ensure that you have received all
the listed items.
Set up Router on Desktop, Rack, or Wall
After unpacking, based on your requirements, you can set up a Cisco 1000 Series Integrated Services Router
on a desktop, a rack, or the wall.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
31

Cisco C1121-4PLTEP Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11i, IEEE 802.11r, IEEE 802.1x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
3G	-
USB version	3.2 Gen 1 (3.1 Gen 1)
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power over Ethernet (PoE) ports quantity	2
Security algorithms	3DES, 802.1x RADIUS, AES, DES
Flash memory	4096 MB
Internal memory type	DRAM
Product color	Silver
Output voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	66 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	226 mm
Width	322 mm
Height	41.9 mm
Weight	1560 g
