Figure 41: Wall mount using key-hole slots - C1109-2P
Horizontal spacing: 7.302 in (185.47 mm)
Vertical spacing: 7.430 in (188.72 mm)
1
Key-hole slots
Figure 42: Wall mount using key-hole slots - C1109-4PLTEP
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
43
Install and Connect the Router
Wall Mount Using Key-hole Slots
