Cisco Catalyst 2960-XR Reference

Table 1: Command Mode Summary
About This ModeExit MethodPromptAccess MethodMode
Use this mode to
•
Change
terminal
settings.
•
Perform basic
tests.
•
Display
system
information.
Enter logout or
quit.
Switch>
Begin a session
using Telnet, SSH,
or console.
User EXEC
Use this mode to
verify commands
that you have
entered. Use a
password to protect
access to this mode.
Enter disable to
exit.
Switch#
While in user EXEC
mode, enter the
enable command.
Privileged EXEC
Use this mode to
configure
parameters that
apply to the entire
switch.
To exit to privileged
EXEC mode, enter
exit or end, or press
Ctrl-Z.
Switch(config)#
While in privileged
EXEC mode, enter
the configure
command.
Global
configuration
Use this mode to
configure VLAN
parameters. When
VTP mode is
transparent, you can
create
extended-range
VLANs (VLAN IDs
greater than 1005)
and save
configurations in the
switch startup
configuration file.
To exit to global
configuration mode,
enter the exit
command.
To return to
privileged EXEC
mode, press Ctrl-Z
or enter end.
Switch(config-vlan)#
While in global
configuration mode,
enter the vlan
vlan-id command.
VLAN
configuration
Use this mode to
configure
parameters for the
Ethernet ports.
To exit to global
configuration mode,
enter exit.
To return to
privileged EXEC
mode, press Ctrl-Z
or enter end.
Switch(config-if)#
While in global
configuration mode,
enter the interface
command (with a
specific interface).
Interface
configuration
Catalyst 2960-XR Switch Stack Manager Command Reference, Cisco IOS Release 15.0(2)EX1
2 OL-29435-01
Using the Command-Line Interface
Command Modes

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
