Figure 22: Threading the Velcro Strap through the Adapter Bracket
Step 3 Place the adapter into the power adapter bracket and secure it using the velcro straps provided.
Figure 23: Securing the Power Adapter to the Adapter Bracket
Velcro strap2Power adapter1
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
40
Installing a Compact Switch
Attaching the Adapter Bracket to the Switch (Optional)

Cisco Catalyst 9200CX Compact Series Specifications

General

Model	Cisco Catalyst 9200CX Compact Series
Software	Cisco IOS XE
Power over Ethernet (PoE)	No
Stacking	Not supported
Weight	5.0 lb (2.3 kg)
Form Factor	Compact
Management	WebUI, CLI, SNMP, Cisco DNA Center
Power Supply	Internal power supply
Memory	4 GB DRAM
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C (-40°F to +158°F)
Relative Humidity	5% to 90% noncondensing
Ports	8, 12, or 24 10/100/1000BASE-T ports
Dimensions	1.73 x 10.5 x 9.45 in. (4.4 x 26.7 x 24 cm)
