Figure 47: Removing a Power Supply Blank Cover
Release handles that are squeezed toward each other1
Do not leave any power supply slot open for any amount of time while the system is powered up. Prior to
inserting a new power supply unit, for instance, when replacing the unit, ensure there are no foreign, conductive
or other objects, or debris in the slot.
Caution
Installing a Power Supply Blank Cover
To install a power supply blank cover, push the blank cover straight and into the bay. You will hear retainer
clips snap into place when installed correctly. You can hold the blank cover by the outside edges when you
perform this task; alternatively, use the release handles to hold the blank cover.
Cisco Catalyst 9600 Series Switches Hardware Installation Guide
88
Installing a Power Supply Unit
Removing and Installing Power Supply Blanks
