Cisco Catalyst C9300-48T User Manual

Figure 69: Simplex LC Cable Connector
Figure 70: Copper SFP Module LC Connector
MPO-12 Connectors
The multi-fiber push on (MPO) connector is a 12-fiber optical connector with a footprint similar to the SC
simplex connector. The MPO connector conforms to the TIA/EIA-604-5 intermateability standard. It is used
for establishing 40G and 100G optical parallel connections.
Figure 71: MPO-12 Fiber-Optic Connector
Guide pins412-fiber ribbon1
Ferrule5Boot2
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
122
Connector and Cable Specifications
MPO-12 Connectors

Cisco Catalyst C9300-48T Specifications

General

Total Ports	48
Default AC Power Supply	715W AC
Switching Capacity	176 Gbps
DRAM	8 GB
Flash Memory	16 GB
Rack Units (RU)	1 RU
Stacking Bandwidth	480 Gbps
Weight	7.25 kg
Power Supply Options	1100W AC
Operating Temperature	0 to 45°C
Operating Humidity	5 to 90% relative humidity
Uplink Ports	4 x 1G Network Module uplink ports (Optional)
