Cisco Catalyst C9300-48T User Manual

Mounting the Switch in a Rack
Procedure
Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.
Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Figure 32: Front-Mounting Position
Number-12 or number-10 Phillips machine
screws
3Phillips machine screw, black1
--Cable guide2
Figure 33: Mid-Mounting Position
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
58
Installing a Switch
Mounting the Switch in a Rack

Cisco Catalyst C9300-48T Specifications

General

Total Ports	48
Default AC Power Supply	715W AC
Switching Capacity	176 Gbps
DRAM	8 GB
Flash Memory	16 GB
Rack Units (RU)	1 RU
Stacking Bandwidth	480 Gbps
Weight	7.25 kg
Power Supply Options	1100W AC
Operating Temperature	0 to 45°C
Operating Humidity	5 to 90% relative humidity
Uplink Ports	4 x 1G Network Module uplink ports (Optional)
