Cisco Catalyst C9300-48T User Manual

Fan modules5MGMT (RJ-45 10/100/1000 management
port)
2
CONSOLE (RJ-45 console port)6StackWise-320 port connectors3
Figure 13: Rear Panel of a C9300LM-48T-4Y
Power supply modules4Ground connectors1
Fixed fans5MGMT (RJ-45 10/100/1000 management
port)
2
CONSOLE (RJ-45 console port)6StackWise-320 port connectors3
Figure 14: Rear Panel of a Cisco Catalyst 9300X Series Switch
Fan modules6USB3.0–SSD port1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
24
Product Overview
Rear Panel

Cisco Catalyst C9300-48T Specifications

General

Total Ports	48
Default AC Power Supply	715W AC
Switching Capacity	176 Gbps
DRAM	8 GB
Flash Memory	16 GB
Rack Units (RU)	1 RU
Stacking Bandwidth	480 Gbps
Weight	7.25 kg
Power Supply Options	1100W AC
Operating Temperature	0 to 45°C
Operating Humidity	5 to 90% relative humidity
Uplink Ports	4 x 1G Network Module uplink ports (Optional)
