a) Stick the labels available with CAT-A-AIRFLOW kit on to each side of the switch as shown in the

following illustration. Make sure you align the holes in the labels with the screw holes in the chassis.

b) Secure the brackets to the chassis using the flat head screws provided with the bracket.

NEBS is supported only with four-point mounting.

Note

Figure 31: Attaching the NEBS-Compliant Air Vent Label to the Switch

NEBS-compliant

CAT-A-AIRFLOW kit

3Number-8 Phillips flat-head screws1

--19-inch bracket2

Cisco Catalyst 9300 Series Switches Hardware Installation Guide

Installing a Switch

Attaching the Rack-Mount Brackets

Questions and Answers:

Need help?

Do you have a question about the Cisco Catalyst C9300-48T and is the answer not in the manual?

General

Total Ports	48
Default AC Power Supply	715W AC
Switching Capacity	176 Gbps
DRAM	8 GB
Flash Memory	16 GB
Rack Units (RU)	1 RU
Stacking Bandwidth	480 Gbps
Weight	7.25 kg
Power Supply Options	1100W AC
Operating Temperature	0 to 45°C
Operating Humidity	5 to 90% relative humidity
Uplink Ports	4 x 1G Network Module uplink ports (Optional)
