Figure 23: Connecting the StackWise Cable in a StackWise Port
Connector screw3Cisco logo1
Connector screw2
Removing and installing the StackWise cable can shorten its useful life. Do not remove and insert
the cable more often than is absolutely necessary (installing and removing it up to 200 times is
supported).
Caution
When you need to remove the StackWise cable from the connector, make sure to fully unscrew the correct
screws. When the connectors are not being used, replace the dust covers.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
37
Switch Installation
Connecting to the StackWise Ports
