Cisco Catalyst Express 500 Getting Started Guide

Chapter 1 Getting Started Guide
Run Express Setup
1-4
Getting Started Guide for the Catalyst Express 500 Switches
OL-9340-01
Run Express Setup
Step 1
You need this equipment to set up the switch:
• A PC with Windows 2000 or XP installed.
• A web browser (Internet Explorer 5.5, 6.0, Netscape 7.1 or later) with JavaScript enabled.
• A straight-through or crossover Category 5 Ethernet cable to connect your PC to the
switch.
You should disable any pop-up blockers or proxy settings in your browser software and any
wireless client running on your PC.
Step 2
Make sure that nothing is connected to the
switch.
Step 3
Power the switch.
When the switch powers on, it begins the
power-on self-test (POST). POST lasts
approximately 1 minute. During POST, the
port and SYSTEM LEDs blink. When POST
completes, the SYSTEM LED turns solid
green.
Step 4
Wait for the SETUP LED to blink green.
When POST has completed and the SYSTEM
LED is solid green, the SETUP LED blinks
green. The switch is ready to be configured.
(If the SETUP LED stops blinking, you can
still continue with the next step.)
2
1
1X
2X
P
O
W
E
R
O
V
E
R
E
T
H
E
R
N
E
T
11X
12X
4
3
6
5
8
7
10
9
1
2
11
14
13
13X
14X
23X
24X
1
6
15
18
17
20
19
22
21
2
4
23
25
25
26
26
S
Y
S
T
E
M
A
L
E
R
T
P
o
E
S
E
T
U
P
R
P
S
Catalyst Express 500
SERIES
Cisco 2960
series
+PoE-4
2
1
1X
2X
P
O
W
E
R
O
V
E
R
E
T
H
E
R
N
E
T
11X
12X
4
3
6
5
8
7
10
9
12
11
14
13
13X
14X
23X
24X
16
15
18
17
20
19
22
21
24
23
25
25
26
26
SYSTEM
ALERT
PoE
S
E
T
U
P
RPS
oE 4
SYSTEM
ALERT
PoE
SETUP

Cisco Catalyst Express 500 Specifications

General

Model	Cisco Catalyst Express 500
Category	Switch
MAC Address Table Size	8000 entries
RAM	64 MB
Flash Memory	16 MB
Authentication Method	RADIUS, TACACS+
Jumbo Frame Support	Yes
Uplink Ports	2 x combo Gigabit Ethernet
PoE Support	Yes
Management	Web-based management interface
Status Indicators	system
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Features	VLAN support, QoS
Power Supply	Internal
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 85% (non-condensing)
