Cisco Firepower 2100 Series Hardware Installation Guide

ACT (Role of a high-availability pair)
• Off—Unit is not configured or enabled in a
high-availability pair.
• Green—Unit is in active mode.
• Amber—Unit is in standby mode.
6SYS (Health)
• Off—System has not booted up yet.
• Green, flashing quickly—System is booting
up.
• Green—Normal system function.
• Amber—System boot up has failed.
• Amber, flashing—Alarm condition, system
needs service or attention and may not boot
properly.
• Green, flashing slowly (twice in 5
seconds)—Cloud connected.
Cisco Defense Orchestrator
(CDO) is valid for FTD 6.7 and
later.
Note
• Green and amber, flashing—Cloud
connection failure.
• Green—Cloud disconnected.
The CDO LED pattern applies to low
touch provisioning (LTP). See the
Firepower Easy Deployment Guide for
Cisco Firepower 1000 or 2100
Firewalls for more information.
Note
5
SSD2
• Off—SSD is not present.
• Green—SSD is present; no activity.
• Green, flashing—SSD is active.
8SSD1
• Off—SSD is not present.
• Green—SSD is present; no activity.
• Green, flashing—SSD is active.
7
FAN
• Off—Environmental subsystem is not active
yet.
• Green—Fans are running normally. It may
take up to one minute for the LED status to
turn green after power is on.
• Amber—One fan has failed. The system can
continue to operate normally, but fan service
is required.
• Amber, flashing—Two or more fans have
failed, or the fan tray has been removed from
the system. Immediate attention is required.
10Fiber Port
• Green—Port is enabled, the link partner is
detected.
• Amber—Port is enabled, but the link partner
is not detected.
• Green, flashing—Port is enabled; network
activity is detected.
9
Cisco Firepower 2100 Series Hardware Installation Guide
14
Overview
Front Panel LEDs
