Figure 50: Firepower 2100 DC Power Supply Module
FAIL and OK LEDs2Handle1
Ejector latch4DC power connector3
Safety Warnings
Take note of the following warnings:
Statement 347Failure to Secure the Expansion Module
To reduce the risk of electric shock, secure the modules with the provided screws.
Warning
Statement 1003DC Power Disconnection
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Warning
Cisco Firepower 2100 Series Hardware Installation Guide
72
Installation, Maintenance, and Upgrade
Connect the DC Power Supply Module
