Enhanced Digital
Return (EDR) System Install
ation
179
5.
P
roceed to next sect
ion for installatio
n.
The following diagram
shows the OPM module
installed on the 1:1 tra
nsmitter
module.
The following d
iagram shows the OPM modu
le installed on the 2:1 tra
nsmitter
module.
CAUTION:
Removing and ins
talling an OPM modul
e can shorten its usefu
l life. Do not
remove and insert
OPM modules more often tha
n is absolutely necess
ary.
198
200
