Cisco IE 3010 Getting Started Guide

9
Cisco IE 3010 Switch Getting Started Guide
78-19582-02
Cisco IE 3010 Switch Getting Started Guide
Managing the Switch
After completing Express Setup and installing the switch in your network, you
can use the CLI for further configuration. You can enter Cisco IOS commands and
parameters through the CLI. Use one of these options to access the CLI:
• Switch RJ-45 Console Port
• Switch USB Console Port
Switch RJ-45 Console Port
1. Connect the RJ-45-to-DB-9 adapter cable to the 9-pin serial port on the PC.
Connect the other end of the cable to the switch console port.
2. Start a terminal-emulation program on the PC.
3. Configure the PC terminal emulation software for 9600 baud, 8 data bits, no
parity, 1 stop bit, and no flow control.
4. Use the CLI to enter configuration commands. See the software configuration
guide and the command reference for more information.
Switch USB Console Port
If you use the USB console port, you must install the Cisco Windows USB device
driver on the PC that is connected to the USB console port. See the switch
hardware installation guide for installation instructions.
1. Connect an USB cable to the PC USB port. Connect the other end of the cable
to the mini-B (5-pin-connector) USB console port on the switch.
2. Start a terminal-emulation program on the PC.
Step 11
Disconnect the switch from the PC, and install the switch in your network. See the “Installing
the Switch” section on page 10.
Step 12
If you changed the static IP address on your PC in Step 2, change it to the previously
configured static IP address.
Step 13
See the “Managing the Switch” section on page 9 for information about configuring and
managing the switch.
