Page #39 background image
3-39
Cisco ISA 3000 Industrial Security Appliance Hardware Installation Guide
Chapter 3 Connecting the ISA 3000
Verifying Connections
Step 1 Insert one power connector into the DC-A receptacle on the device front panel, and the other into the
DC-B receptacle.
Warning
Failure to securely tighten the captive screws can result in an electrical arc if the connector is
accidentally removed. Statement 397
Warning
When you connect or disconnect the power and/or alarm connector with power applied, an
electrical arc can occur. This could cause an explosion in hazardous area installations. Be sure
that all power is removed from the device and any other circuits. Be sure that power cannot be
accidentally turned on or verify that the area is nonhazardous before proceeding.
Statement 1058
Step 2 Use a ratcheting torque flathead screwdriver to tighten the captive screws on the sides of the power
connectors to 2 in-lb (0.23 N-m).
Step 3 When you are testing the device, one power source is sufficient. If you are installing the device and are
using a second power source, repeat this procedure for the second power connector (DC-B), which
installs just below the primary power connector (DC-A).
Step 4 When you are installing the device, secure the wires coming from the power connector so that they
cannot be disturbed by casual contact. For example, use tie wraps to secure the wires to the rack.
Verifying Connections
To verify that all devices are properly connected to the Cisco ISA 3000, first turn on all the connected
devices, then check the LEDs. To verify Cisco ISA 3000 operation, refer to the following table:
LED Activity Description
System Power Status Off — No power
Green Steady on — Normal operation
Green Flashing — Boot up phase and POST
Red Flashing — BIOS
Red — System is not functioning properly.
MGMT Management Port Status Off — No link (default)
Green Steady on — Port link with no activity
Green Flashing — Transmitting and Receiving data
DC_A
DC_B
DC Power Status Off — Power is not present
Green Steady on — Power is present on the associated
circuit. (Hardware controlled)
Red Steady on — Power is not present on the associated
circuit, and the system is configured for dual-input power.
