Cisco ISA 3000 Connecting Instructions

DescriptionActivityLED
Off — Alarm Out not configured or the system is
off (Default)
Green Steady on — Alarm Out is configured, no
alarm detected.
Red Steady on — Minor alarm detected
Red Flashing — Major alarm detected
Alarm monitoringAlarm Out
Off — Alarm Out not configured or the system is
off (Default)
Green Steady on — Alarm Out is configured, no
alarm detected.
Red Steady on — Minor alarm detected
Red Flashing — Major alarm detected
Alarm monitoringAlarm In 1&2
Off — No link
Green Steady on — Link is up
Green Flashing — Transmitting and Receiving
data
Amber — Fault, check log.
Port 1&2 or 3&4 LEDs flashing amber together
— Those two ports are in bypass mode and the
system is up.
Link StatusEthernet Ports
Off — RJ-45 is being used for console
Green — Mini USB is being used for console
Console connection statusConsole
The Ethernet LAN Ports pairs 1&2 or 3&4 (copper
sku only) will blink amber together every 100ms
(fast blink), when there is system power.
Bypass Mode IndicatorBYPASS
Connecting Alarm Circuits
After the device is installed, you are ready to connect the DC power and alarm connections.
The device has two alarm input and one alarm output relay circuits for external alarms. The alarm input circuits
are designed to sense if the alarm input is open or closed relative to the alarm input reference pin. Each alarm
input can be configured as an open or closed contact. The alarm output relay circuit has a normally open and
a normally closed contact.
Alarm signals are connected to the device through the six-pin alarm connector. Three connections are dedicated
to the two alarm input circuits: alarm input 1, alarm input 2, and a reference ground. An alarm input and the
reference ground wiring connection are required to complete a single alarm input circuit. The three remaining
connections are for the alarm output circuit: a normally open output, a normally closed output, and a common
Connecting the Cisco ISA 3000
8
Connecting the Cisco ISA 3000
Connecting Alarm Circuits

Cisco ISA 3000 Specifications

General

Firewall	Yes
VPN	Yes
Concurrent Sessions	100, 000
Memory	4 GB
Flash Memory	8 GB
