Chapter 2 Introducing the Cisco ISE-3300 Series Hardware
ISE-3315, ISE-3355, and ISE-3395 Hardware Summary
ISE-3315 Rear Panel Features
Figure 2-4, Figure 2-5, and the accompanying tables illustrate and describe the ISE-3315 rear panel
features and LEDs.
Figure 2-4 Cisco ISE-3315 Rear Panel Features
4
HDD Activity LED Flashing green = Ongoing drive activity
Off = No drive activity
5
Locator Button/LED Flashing blue = The Locator button has been pressed
6
System Health LED Off = System health is normal
Amber = A pre-failure system threshold has been reached, which
can be caused by any of the following conditions:
• At least one fan failure (system or processor fan)
• At least one of the temperature sensors reached critical level
(system or processor thermal sensors)
• At least one memory module failure
• A power supply unit error has occurred
1
Power Supply Cable Socket
7
NIC 1 (eth0) GbE Interface
2
NIC 3 (eth2) Add-On Card
8
Rear USB Port 4
3
NIC 4 (eth3) Add-On Card
9
Rear USB Port 3
4
Serial Port
10
Console Port
5
Video Port
6
NIC 2 (eth1) GbE Interface
