Chapter 2 Introducing the Cisco ISE-3300 Series Hardware
ISE-3315, ISE-3355, and ISE-3395 Hardware Summary
Figure 2-5 Cisco ISE-3315 Rear Panel LEDs
ISE-3355 Serial Number Location
The serial number label is located at the lower left of the front-panel of the ISE-3355. (See Figure 2-6.)
CPI figure for the Cisco ISE-3355 still needs to be created.
Figure 2-6 ISE-3355 Appliance Serial Number Location
Note The serial number for the ISE-3355 is seven characters in length. You can also view the ISE-3355 serial
number location on the Cisco Support website using the Cisco Product Identification Tool. For details,
see Cisco Product Identification Tool, page 218.
1
NIC 1 (eth0) Activity LED Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
2
NIC 1 (eth0) link LED Green = Link exists
Off = No link exists
3
NIC 2 (eth1) activity LED Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
4
NIC 2 (eth1) link LED Green = Link exists
Off = No link exists
Cisco ISE 3355 Series
Identity Services Engine
279776
CISCO
XXXXNNNNNNN
