Linksys E4200
Edit To change the access settings of a shared folder, click
this option . Go to “Edit a Shared Folder” on page 25 .
Delete To delete a shared folder, click this option .
Chapter 2: Advanced Configuration
Create a Shared Folder
Shared Folders Summary
For each folder, the Display Name, Partition, Shared
Folder location, and Groups with Access are displayed .
Disk > Shared Folders Summary
Click Close to exit this screen and return to the Disk
screen .
Format Disk
Disk To format the disk as FAT32, select the disk you want
to format, and then click Format Disk . (If your disk was
formatted with multiple partitions, then the formatting
will delete them and create a single partition .) The Claim
Disk screen appears .
Claim Disk
Enter a partition’s name Enter a name for the partition .
Click Format and follow the on-screen instructions .
Disk > Shared Folder
1 . In the Display Name field, enter a name for the shared
folder .
Shared Folder > Enter Display Name
2 . The Partition name is displayed . If the shared folder
should include the entire partition, select Share Entire
Partition and go to step 4 .
Disk > Claim Disk
On the Disk screen, click Refresh to update the on-screen
information .
Shared Folder > Share Entire Partition
NOTE: If you select Share Entire Partition,
then all of the Groups with Access (see step 4)
can access any folder in the partition .
Maximum Performance Wireless-N Router
24

Cisco Linksys E4200 Specifications

General

Wireless Standard	802.11a/b/g/n
Frequency Bands	2.4 GHz and 5 GHz
USB Ports	1 x USB 2.0
Antenna Type	Internal
Wired Speed	10/100/1000 Mbps
Ethernet Ports	4 x 10/100/1000 Mbps LAN
Security Features	WPA/WPA2
Maximum Data Rate	450 Mbps (5 GHz)
Weight	0.32 kg
